Using QEnvS with RL libraries

QEnvS offers three interfaces to the same physics. They share the reward, observation and termination semantics of the functional environment, so results are comparable.

Interface Class Use it when
Functional JAX qenvs.make(...): reset(key), step(state, action) JAX-native training (PPO/SAC written in JAX, evolution strategies, GRAPE), jit/vmap/grad over episodes. Fastest, differentiable.
Gymnasium qenvs.wrappers.GymnasiumEnv Single-environment libraries and quick experiments (SB3 DummyVecEnv, check_env, notebooks).
Gymnasium vector qenvs.wrappers.vector.GymnasiumVectorEnv Batched numpy training loops (CleanRL, SB3 through a vec adapter, any gymnasium.vector consumer). One jitted vmap steps all sub-environments.

Install the Gymnasium extra with pip install 'qenvs[gym]' (gymnasium >= 1.0).

Normalised actions

All QEnvS tasks have a symmetric control bound env.action_bound (2.0 for qubit/StateTransfer-v0). Gymnasium's checker warns about non-normalised Box action spaces and SB3 and CleanRL assume [-1, 1]. Pass normalize_actions=True:

env = GymnasiumEnv(qenvs.make("qubit/StateTransfer-v0"), normalize_actions=True)
env.action_space  # Box(-1.0, 1.0, (1,), float32)

The action is multiplied by env.action_bound before stepping, exactly (a test compares normalize_actions=True with the unscaled wrapper bit for bit). The environment still clips to the bound, so an out-of-range policy output saturates at +-action_bound. The observation space is unchanged: it is Box(-inf, inf) (the quantum state components are bounded by 1 in modulus, but the space is not declared that way), so the checker's unbounded-observation warning remains.

Reward and termination semantics

  • The reward at each step is the fidelity gain (for state transfer), so the undiscounted return of an episode equals the final fidelity minus the initial fidelity.
  • Every episode ends with terminated=True after exactly env.horizon steps. truncated is never True. QEnvS tasks are fixed-duration control problems: the total pulse time is part of the task and the return is defined at that final time. Reaching the horizon is therefore a genuine terminal state, not a time-limit cut-off of a longer process. Value bootstrapping must stop there, and that is what terminated=True tells the library (a time-limit truncated=True would make PPO/SAC bootstrap from a state that has no future). Do not wrap QEnvS environments in TimeLimit and expect different behaviour.
  • Time-dependent policies are possible: the observation contains the normalised time t/T.

Vector environment and autoreset

GymnasiumVectorEnv(env, num_envs, *, seed=0, normalize_actions=False) implements the gymnasium>=1.0 VectorEnv API with numpy inputs and outputs:

  • observation_space / action_space are batched, single_observation_space / single_action_space describe one sub-environment.
  • reset(seed=s) returns (obs[num_envs, obs_dim], infos); step(actions[num_envs, action_dim]) returns (obs, reward, terminated, truncated, infos) as float32, float32, bool, bool.
  • Every returned array (observations, rewards, terminated, truncated and each info value) is a writable numpy copy, so in-place edits and gymnasium.wrappers.vector wrappers such as ClipReward, VectorizeTransformReward and VectorizeTransformObservation work (tested).
  • step needs actions of shape (num_envs, action_dim) exactly. A 1-D action of shape (num_envs,) is rejected with ValueError("actions must have shape ..."), there is no implicit reshape.
  • Infos are dicts of batched arrays (infos["fidelity"] has shape (num_envs,)) with the usual _key boolean masks (all True, since every sub-environment reports every key).
  • Episode keys follow qenvs.keys.episode_key(run_key, i) = fold_in(PRNGKey(seed), i). The j-th episode of sub-environment b is episode i = j * num_envs + b, so the vector environment replays the episodes of GymnasiumEnv(seed=seed) in interleaved order (tested, including a random-reset toy environment). Since 0.3; in 0.2 sub-environment b followed GymnasiumEnv(seed=seed + b). The built-in tasks reset deterministically, so their episodes are unchanged.

Autoreset mode is AutoresetMode.NEXT_STEP (declared in metadata["autoreset_mode"] on gymnasium >= 1.1, where the enum exists; the version in the development venv is 1.4.0). On the step where an episode ends you receive the true final observation and terminated=True. On the next call the action of that sub-environment is ignored and you receive the new initial observation, reward 0, terminated=False, truncated=False. An episode therefore occupies horizon + 1 calls. Libraries that expect SAME_STEP must not be used without adaptation. Calling reset() while an autoreset is pending discards it: the next step uses its action normally (tested). Gymnasium 1.0 has no AutoresetMode enum: there NEXT_STEP is the only behaviour and nothing needs declaring, so the class omits the metadata key. The gymnasium 1.0 path is tested: both wrapper test files (25 tests) pass on gymnasium 1.0.0 with jax 0.4.36 (the CI lowest-versions environment).

gymnasium.wrappers.vector.RecordEpisodeStatistics works and reports episode["r"], episode["l"] (tested).

CleanRL-style loop (tested)

This script is executed in the test suite as a random-policy loop (test_cleanrl_style_loop_three_episodes) and was run standalone to produce the output below.

import numpy as np

import qenvs
from qenvs.wrappers.vector import GymnasiumVectorEnv

num_envs = 8
envs = GymnasiumVectorEnv(
    qenvs.make("qubit/StateTransfer-v0", horizon=20, dt=0.1),
    num_envs,
    seed=0,
    normalize_actions=True,
)
envs.action_space.seed(0)  # makes the random policy, and so the output below, deterministic
obs, _ = envs.reset(seed=0)
episodic_return = np.zeros(num_envs)
finished = []
for _ in range(3 * 21):  # 3 episodes (20 steps + 1 autoreset step each)
    actions = envs.action_space.sample()  # replace by policy(obs)
    obs, rewards, terminations, truncations, infos = envs.step(actions)
    episodic_return += rewards
    for i in np.flatnonzero(terminations | truncations):
        finished.append((episodic_return[i], infos["fidelity"][i]))
        episodic_return[i] = 0.0
print(len(finished), "episodes, mean return", np.mean([r for r, _ in finished]))

Output: 24 episodes, mean return 0.0686... (3 episodes times 8 environments, random actions from action_space.seed(0); the mean return equals the mean final fidelity here, 0.0686...). Note that the reward on the autoreset call is 0, so summing rewards across it is safe.

Stable-Baselines3 (untested)

SB3 is not installed in the development environment, so the following is untested. It uses the single-environment wrapper because SB3 builds its own vectorisation.

import qenvs
from qenvs.wrappers import GymnasiumEnv
from stable_baselines3 import SAC
from stable_baselines3.common.env_util import make_vec_env


def make():
    return GymnasiumEnv(qenvs.make("qubit/StateTransfer-v0"), normalize_actions=True)


env = make_vec_env(make, n_envs=4)
model = SAC("MlpPolicy", env, verbose=1)
model.learn(total_timesteps=20_000)

The single-environment wrapper steps one ODE solve per call (about 4k steps/s on CPU). For throughput prefer the vector class with a library that consumes gymnasium.vector directly, or the functional API.

Measured throughput

qubit/StateTransfer-v0 with defaults (horizon 20, dt 0.1), normalize_actions=True, zero actions, CPU only (JAX_PLATFORMS=cpu, x64 off), steady state after compilation, on a shared 64-core machine while other jobs were running, so treat the numbers as order of magnitude:

Interface num_envs steps/s
GymnasiumEnv 1 4.2e3
GymnasiumVectorEnv 1 8.6e3
GymnasiumVectorEnv 64 2.2e5
GymnasiumVectorEnv 1024 1.2e6
functional jit(vmap(step)) 1024 1.4e6

The vector class costs up to tens of percent over the raw functional vmap at large batch (host transfers and copies, autoreset selection); repeated measurements here gave between no measurable gap and about 15 percent, and the machine is shared, so the gap is not resolved more finely than that. Note that the vector step also evaluates reset for every sub-environment each call (selected with where), which is negligible for the bundled tasks but would matter for a task with an expensive reset.

Limitations

  • CPU numbers only; no GPU measurement was made.
  • The vector class is not a jax.Array interface: for end-to-end JAX training avoid the numpy round trip and use the functional API.
  • render is not supported; close releases nothing, it only sets closed=True.
